MOC wide-angle image R18-02038

context image for 2037


MOC wide-angle image R18-02038
MOC wide-angle image R18-02038
View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)
View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image R18-02038

Acquisition parameters
     Image ID (picno): R18-02038
     Image start time: 2004-06-26T01:02:35.44 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      0.96
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    270.81°W
 Latitude of image center:      0.76°N
       Scaled pixel width:    256.48   meters
      Scaled image  width:    124.20   km
      Scaled image height:    118.28   km
     Solar longitude (Ls):     52.22°
    Local True Solar Time:     14.30   decimal hours
           Emission angle:     18.35°
          Incidence angle:     38.81°
              Phase angle:     28.36°
            North azimuth:     92.89°
              Sun azimuth:     34.25°
      Spacecraft altitude:    388.25   km
           Slant distance:    406.73   km

Policy regarding use of processed images

Release date: 6 April 2005
