MOC wide-angle image R12-03842

context image for 3841


MOC wide-angle image R12-03842
MOC wide-angle image R12-03842
View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)
View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image R12-03842

Acquisition parameters
     Image ID (picno): R12-03842
     Image start time: 2003-12-29T11:13:44.94 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      0.94
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:     11 (decimal)
Derived values
Longitude of image center:    354.88°W
 Latitude of image center:     14.78°N
       Scaled pixel width:    260.83   meters
      Scaled image  width:    126.36   km
      Scaled image height:    118.24   km
     Solar longitude (Ls):    324.47°
    Local True Solar Time:     13.40   decimal hours
           Emission angle:     18.27°
          Incidence angle:     35.88°
              Phase angle:     49.21°
            North azimuth:     92.86°
              Sun azimuth:    309.62°
      Spacecraft altitude:    395.33   km
           Slant distance:    413.96   km

Policy regarding use of processed images

Release date: 27 September 2004
