MOC wide-angle image R12-03460

context image for 3459


MOC wide-angle image R12-03460
MOC wide-angle image R12-03460
View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)
View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image R12-03460

Acquisition parameters
     Image ID (picno): R12-03460
     Image start time: 2003-12-27T08:16:57.97 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      0.90
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:     11 (decimal)
Derived values
Longitude of image center:    331.94°W
 Latitude of image center:     28.37°N
       Scaled pixel width:    266.97   meters
      Scaled image  width:    129.48   km
      Scaled image height:    116.28   km
     Solar longitude (Ls):    323.28°
    Local True Solar Time:     13.35   decimal hours
           Emission angle:     18.21°
          Incidence angle:     47.43°
              Phase angle:     62.01°
            North azimuth:     92.97°
              Sun azimuth:    300.26°
      Spacecraft altitude:    405.71   km
           Slant distance:    424.64   km

Policy regarding use of processed images

Release date: 27 September 2004
