MOC wide-angle image R12-01431

context image for 1430


MOC wide-angle image R12-01431
MOC wide-angle image R12-01431
View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)
View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image R12-01431

Acquisition parameters
     Image ID (picno): R12-01431
     Image start time: 2003-12-12T22:48:48.68 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      0.94
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:     11 (decimal)
Derived values
Longitude of image center:    327.60°W
 Latitude of image center:      9.69°N
       Scaled pixel width:    260.02   meters
      Scaled image  width:    125.94   km
      Scaled image height:    117.42   km
     Solar longitude (Ls):    315.10°
    Local True Solar Time:     13.45   decimal hours
           Emission angle:     18.30°
          Incidence angle:     34.72°
              Phase angle:     47.78°
            North azimuth:     92.87°
              Sun azimuth:    311.48°
      Spacecraft altitude:    393.84   km
           Slant distance:    412.47   km

Policy regarding use of processed images

Release date: 27 September 2004
