MOC wide-angle image R12-01014

context image for 1013


MOC wide-angle image R12-01014
MOC wide-angle image R12-01014
View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)
View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image R12-01014

Acquisition parameters
     Image ID (picno): R12-01014
     Image start time: 2003-12-09T22:12:15.85 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      0.96
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:     11 (decimal)
Derived values
Longitude of image center:    347.58°W
 Latitude of image center:      9.04°N
       Scaled pixel width:    260.28   meters
      Scaled image  width:    126.06   km
      Scaled image height:    117.83   km
     Solar longitude (Ls):    313.35°
    Local True Solar Time:     13.46   decimal hours
           Emission angle:     18.45°
          Incidence angle:     34.74°
              Phase angle:     47.92°
            North azimuth:     93.07°
              Sun azimuth:    311.87°
      Spacecraft altitude:    393.97   km
           Slant distance:    412.91   km

Policy regarding use of processed images

Release date: 27 September 2004
