MOC wide-angle image R12-00171

context image for 170


MOC wide-angle image R12-00171
MOC wide-angle image R12-00171
View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)
View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image R12-00171

Acquisition parameters
     Image ID (picno): R12-00171
     Image start time: 2003-12-02T15:36:51.83 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      0.92
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      5 (decimal)
Derived values
Longitude of image center:    319.42°W
 Latitude of image center:     19.59°N
       Scaled pixel width:    264.92   meters
      Scaled image  width:    128.39   km
      Scaled image height:    117.12   km
     Solar longitude (Ls):    309.12°
    Local True Solar Time:     13.45   decimal hours
           Emission angle:     18.31°
          Incidence angle:     44.40°
              Phase angle:     58.59°
            North azimuth:     92.97°
              Sun azimuth:    303.16°
      Spacecraft altitude:    401.73   km
           Slant distance:    420.72   km

Policy regarding use of processed images

Release date: 27 September 2004
