MOC wide-angle image R10-05243

context image for 5242


MOC wide-angle image R10-05243
MOC wide-angle image R10-05243
View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)
View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image R10-05243

Acquisition parameters
     Image ID (picno): R10-05243
     Image start time: 2003-10-31T04:08:43.79 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.02
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:     11 (decimal)
Derived values
Longitude of image center:     94.24°W
 Latitude of image center:     58.32°S
       Scaled pixel width:    241.76   meters
      Scaled image  width:    117.62   km
      Scaled image height:    118.28   km
     Solar longitude (Ls):    289.69°
    Local True Solar Time:     14.07   decimal hours
           Emission angle:     18.23°
          Incidence angle:     41.19°
              Phase angle:     26.48°
            North azimuth:     96.25°
              Sun azimuth:     50.11°
      Spacecraft altitude:    369.55   km
           Slant distance:    387.03   km

Policy regarding use of processed images

Release date: 27 September 2004
