MOC wide-angle image M22-02510

context image for 2509


MOC wide-angle image M22-02510
MOC wide-angle image M22-02510
View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)
View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M22-02510

Acquisition parameters
     Image ID (picno): M22-02510
     Image start time: 2000-12-31T21:49:38.29 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.02
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     3A (hexadecimal)
          Offset mode:      8 (decimal)
Derived values
Longitude of image center:    240.01°W
 Latitude of image center:     12.51°S
       Scaled pixel width:    239.42   meters
      Scaled image  width:    115.96   km
      Scaled image height:    118.22   km
     Solar longitude (Ls):     96.89°
    Local True Solar Time:     14.36   decimal hours
           Emission angle:      3.45°
          Incidence angle:     51.13°
              Phase angle:     48.87°
            North azimuth:     93.08°
              Sun azimuth:     50.37°
      Spacecraft altitude:    379.34   km
           Slant distance:    379.96   km

Policy regarding use of processed images

Release date: 8 October 2001
