MOC wide-angle image M22-01305

Science Campaign F Red-Blue Wide Angle Seasonal Monitoring Image


MOC wide-angle image M22-01305
MOC wide-angle image M22-01305
View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)
View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M22-01305

Acquisition parameters
     Image ID (picno): M22-01305
     Image start time: 2000-12-17T22:08:30.71 SCET
         Image  width:    176      pixels
         Image height:   7200      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      0.96
   Crosstrack summing:      6
    Downtrack summing:      6
     Compression type: MOC-NONE
            Gain mode:     2A (hexadecimal)
          Offset mode:      5 (decimal)
Derived values
Longitude of image center:     28.58°W
 Latitude of image center:     30.88°N
       Scaled pixel width:   1536.53   meters
      Scaled image  width:    284.58   km
      Scaled image height:  10173.25   km
     Solar longitude (Ls):     90.69°
    Local True Solar Time:     13.72   decimal hours
           Emission angle:      4.42°
          Incidence angle:     29.56°
              Phase angle:     25.13°
            North azimuth:     93.05°
              Sun azimuth:      0.24°
      Spacecraft altitude:    405.86   km
           Slant distance:    406.94   km

Policy regarding use of processed images

Release date: 8 October 2001
