MOC wide-angle image M22-01298

Science Campaign F Red-Blue Wide Angle Seasonal Monitoring Image


MOC wide-angle image M22-01298
MOC wide-angle image M22-01298
View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)
View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M22-01298

Acquisition parameters
     Image ID (picno): M22-01298
     Image start time: 2000-12-17T18:13:02.83 SCET
         Image  width:    176      pixels
         Image height:   7200      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      0.96
   Crosstrack summing:      6
    Downtrack summing:      6
     Compression type: MOC-NONE
            Gain mode:     2A (hexadecimal)
          Offset mode:      5 (decimal)
Derived values
Longitude of image center:    331.31°W
 Latitude of image center:     30.90°N
       Scaled pixel width:   1540.99   meters
      Scaled image  width:    285.42   km
      Scaled image height:  10172.09   km
     Solar longitude (Ls):     90.62°
    Local True Solar Time:     13.72   decimal hours
           Emission angle:      4.52°
          Incidence angle:     29.54°
              Phase angle:     25.01°
            North azimuth:     93.07°
              Sun azimuth:      0.20°
      Spacecraft altitude:    406.93   km
           Slant distance:    408.07   km

Policy regarding use of processed images

Release date: 8 October 2001
