MOC wide-angle image M22-01192

Science Campaign F Red-Blue Wide Angle Seasonal Monitoring Image


MOC wide-angle image M22-01192
MOC wide-angle image M22-01192
View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)
View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M22-01192

Acquisition parameters
     Image ID (picno): M22-01192
     Image start time: 2000-12-16T16:42:57.47 SCET
         Image  width:    176      pixels
         Image height:   7200      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      0.96
   Crosstrack summing:      6
    Downtrack summing:      6
     Compression type: MOC-NONE
            Gain mode:     2A (hexadecimal)
          Offset mode:      5 (decimal)
Derived values
Longitude of image center:    319.04°W
 Latitude of image center:     30.82°N
       Scaled pixel width:   1539.78   meters
      Scaled image  width:    285.19   km
      Scaled image height:  10174.06   km
     Solar longitude (Ls):     90.15°
    Local True Solar Time:     13.72   decimal hours
           Emission angle:      4.49°
          Incidence angle:     29.49°
              Phase angle:     24.99°
            North azimuth:     93.12°
              Sun azimuth:      0.36°
      Spacecraft altitude:    406.64   km
           Slant distance:    407.76   km

Policy regarding use of processed images

Release date: 8 October 2001
