MOC wide-angle image M22-00006

context image for 5


MOC wide-angle image M22-00006
MOC wide-angle image M22-00006
View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)
View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M22-00006

Acquisition parameters
     Image ID (picno): M22-00006
     Image start time: 2000-12-01T02:20:53.16 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-DCT-1
            Gain mode:     4A (hexadecimal)
          Offset mode:      5 (decimal)
Derived values
Longitude of image center:    245.08°W
 Latitude of image center:      3.86°S
       Scaled pixel width:    241.51   meters
      Scaled image  width:    116.94   km
      Scaled image height:    118.93   km
     Solar longitude (Ls):     83.29°
    Local True Solar Time:     14.26   decimal hours
           Emission angle:      3.43°
          Incidence angle:     43.87°
              Phase angle:     41.40°
            North azimuth:     93.10°
              Sun azimuth:     46.07°
      Spacecraft altitude:    382.45   km
           Slant distance:    383.07   km

Policy regarding use of processed images

Release date: 8 October 2001
