MOC wide-angle image M22-00004

context image for 3


MOC wide-angle image M22-00004
MOC wide-angle image M22-00004
View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)
View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M22-00004

Acquisition parameters
     Image ID (picno): M22-00004
     Image start time: 2000-12-01T02:14:02.41 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     2A (hexadecimal)
          Offset mode:      5 (decimal)
Derived values
Longitude of image center:    242.21°W
 Latitude of image center:     25.08°S
       Scaled pixel width:    236.17   meters
      Scaled image  width:    114.48   km
      Scaled image height:    118.29   km
     Solar longitude (Ls):     83.29°
    Local True Solar Time:     14.34   decimal hours
           Emission angle:      3.42°
          Incidence angle:     60.57°
              Phase angle:     58.58°
            North azimuth:     93.40°
              Sun azimuth:     56.52°
      Spacecraft altitude:    374.86   km
           Slant distance:    375.46   km

Policy regarding use of processed images

Release date: 8 October 2001
