MOC wide-angle image M20-01593

context image for 1592


MOC wide-angle image M20-01593
MOC wide-angle image M20-01593
View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)
View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M20-01593

Acquisition parameters
     Image ID (picno): M20-01593
     Image start time: 2000-10-27T02:50:58.82 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:      5 (decimal)
Derived values
Longitude of image center:    229.43°W
 Latitude of image center:      6.19°S
       Scaled pixel width:    241.10   meters
      Scaled image  width:    116.75   km
      Scaled image height:    118.96   km
     Solar longitude (Ls):     68.00°
    Local True Solar Time:     14.15   decimal hours
           Emission angle:      3.44°
          Incidence angle:     43.25°
              Phase angle:     40.83°
            North azimuth:     93.10°
              Sun azimuth:     47.10°
      Spacecraft altitude:    381.84   km
           Slant distance:    382.46   km

Policy regarding use of processed images

Release date: 8 October 2001
