MOC narrow-angle image M19-00047

Traverse across crater at 65.6 N 327.6 W


MOC narrow-angle image M19-00047
Map projection is sinusoidal, using 327.89 degrees W as prime meridian 		MOC red wide-angle context image M19-00048
MOC narrow-angle image M19-00047
Map projection is sinusoidal, using 327.89 degrees W as prime meridian 		MOC red wide-angle context image M19-00048
View full-size processed and map-projected image
(lossy JPEG, medium quality, rapid download)		 View full-size processed and map-projected image
(lossy JPEG, medium quality, rapid download)
View full-size processed and map-projected image
(lossless GIF, best quality, slow download)		 View full-size processed and map-projected image
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)		 View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)
View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)		 View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)
Download processed image in PDS .IMG format Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format Download compressed raw data in PDS .IMQ format

Ancillary data for MOC narrow-angle image M19-00047

Acquisition parameters
     Image ID (picno): M19-00047
     Image start time: 2000-09-01T21:28:47.81 SCET
         Image  width:    512      pixels
         Image height:   4864      pixels
Line integration time:      0.4821 millisec
   Pixel aspect ratio:      0.89
   Crosstrack summing:      4
    Downtrack summing:      4
     Compression type: MOC-PRED-X-5
            Gain mode:     6A (hexadecimal)
          Offset mode:     30 (decimal)
Derived values
Longitude of image center:    327.89°W
 Latitude of image center:     65.55°N
       Scaled pixel width:      6.39   meters
      Scaled image  width:      3.28   km
      Scaled image height:     27.81   km
     Solar longitude (Ls):     43.69°
    Local True Solar Time:     13.42   decimal hours
           Emission angle:      0.10°
          Incidence angle:     50.51°
              Phase angle:     50.58°
            North azimuth:     97.11°
              Sun azimuth:    304.04°
      Spacecraft altitude:    429.49   km
           Slant distance:    429.49   km

Policy regarding use of processed images

Release date: 8 October 2001
