MOC wide-angle image M12-01668

context image for 1667


MOC wide-angle image M12-01668
MOC wide-angle image M12-01668
View full-size image, processed, in sinusoidal projection using 236.03°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 236.03°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M12-01668

Acquisition parameters
     Image ID (picno): M12-01668
     Image start time: 2000-02-16T08:20:05.19 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:     12 (decimal)
Derived values
Longitude of image center:    236.03°W
Latitude  of image center:      8.67°S
       Scaled pixel width:    239.78   meters
      Scaled image  width:    116.11   km
      Scaled image height:    119.03   km
     Solar longitude (Ls):    302.43°
    Local True Solar Time:     13.34   decimal hours
           Emission angle:      3.44°
          Incidence angle:     23.19°
              Phase angle:     20.32°
            North azimuth:     93.06°
              Sun azimuth:    328.52°
      Spacecraft altitude:    379.80   km
           Slant distance:    380.42   km

Policy regarding use of processed images

Release date: 16 October 2000
