MOC wide-angle image M12-01561

context image for 1560


MOC wide-angle image M12-01561
MOC wide-angle image M12-01561
View full-size image, processed, in sinusoidal projection using 224.80°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 224.80°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M12-01561

Acquisition parameters
     Image ID (picno): M12-01561
     Image start time: 2000-02-15T06:52:54.20 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.02
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:     12 (decimal)
Derived values
Longitude of image center:    224.80°W
Latitude  of image center:      1.93°S
       Scaled pixel width:    242.17   meters
      Scaled image  width:    117.26   km
      Scaled image height:    119.69   km
     Solar longitude (Ls):    301.80°
    Local True Solar Time:     13.33   decimal hours
           Emission angle:      3.49°
          Incidence angle:     27.48°
              Phase angle:     25.12°
            North azimuth:     92.97°
              Sun azimuth:    316.92°
      Spacecraft altitude:    383.44   km
           Slant distance:    384.08   km

Policy regarding use of processed images

Release date: 16 October 2000
