MOC wide-angle image M12-01147

context image for 1146


MOC wide-angle image M12-01147
MOC wide-angle image M12-01147
View full-size image, processed, in sinusoidal projection using 259.93°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 259.93°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M12-01147

Acquisition parameters
     Image ID (picno): M12-01147
     Image start time: 2000-02-11T06:42:53.12 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:     10 (decimal)
Derived values
Longitude of image center:    259.93°W
Latitude  of image center:     19.20°S
       Scaled pixel width:    236.77   meters
      Scaled image  width:    114.72   km
      Scaled image height:    117.34   km
     Solar longitude (Ls):    299.40°
    Local True Solar Time:     13.42   decimal hours
           Emission angle:      3.51°
          Incidence angle:     20.24°
              Phase angle:     16.81°
            North azimuth:     93.31°
              Sun azimuth:    352.33°
      Spacecraft altitude:    375.40   km
           Slant distance:    376.03   km

Policy regarding use of processed images

Release date: 16 October 2000
