MOC wide-angle image M12-00972

context image for 971


MOC wide-angle image M12-00972
MOC wide-angle image M12-00972
View full-size image, processed, in sinusoidal projection using 265.49°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 265.49°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M12-00972

Acquisition parameters
     Image ID (picno): M12-00972
     Image start time: 2000-02-09T05:44:34.27 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:     10 (decimal)
Derived values
Longitude of image center:    265.49°W
Latitude  of image center:     10.74°S
       Scaled pixel width:    238.84   meters
      Scaled image  width:    115.66   km
      Scaled image height:    119.03   km
     Solar longitude (Ls):    298.18°
    Local True Solar Time:     13.40   decimal hours
           Emission angle:      3.47°
          Incidence angle:     23.21°
              Phase angle:     20.35°
            North azimuth:     93.17°
              Sun azimuth:    331.38°
      Spacecraft altitude:    378.34   km
           Slant distance:    378.97   km

Policy regarding use of processed images

Release date: 16 October 2000
