MOC wide-angle image M12-00800

context image for 799


MOC wide-angle image M12-00800
MOC wide-angle image M12-00800
View full-size image, processed, in sinusoidal projection using 241.34°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 241.34°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M12-00800

Acquisition parameters
     Image ID (picno): M12-00800
     Image start time: 2000-02-07T02:45:59.92 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:     10 (decimal)
Derived values
Longitude of image center:    241.34°W
Latitude  of image center:     10.38°S
       Scaled pixel width:    239.20   meters
      Scaled image  width:    115.84   km
      Scaled image height:    119.09   km
     Solar longitude (Ls):    296.90°
    Local True Solar Time:     13.41   decimal hours
           Emission angle:      3.48°
          Incidence angle:     23.69°
              Phase angle:     20.86°
            North azimuth:     93.11°
              Sun azimuth:    330.22°
      Spacecraft altitude:    378.90   km
           Slant distance:    379.53   km

Policy regarding use of processed images

Release date: 16 October 2000
