MOC wide-angle image M12-00798

context image for 797


MOC wide-angle image M12-00798
MOC wide-angle image M12-00798
View full-size image, processed, in sinusoidal projection using 240.09°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 240.09°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M12-00798

Acquisition parameters
     Image ID (picno): M12-00798
     Image start time: 2000-02-07T02:42:59.92 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:     10 (decimal)
Derived values
Longitude of image center:    240.09°W
Latitude  of image center:     19.68°S
       Scaled pixel width:    236.82   meters
      Scaled image  width:    114.74   km
      Scaled image height:    119.17   km
     Solar longitude (Ls):    296.90°
    Local True Solar Time:     13.45   decimal hours
           Emission angle:      3.46°
          Incidence angle:     20.60°
              Phase angle:     17.23°
            North azimuth:     93.30°
              Sun azimuth:    352.10°
      Spacecraft altitude:    375.54   km
           Slant distance:    376.15   km

Policy regarding use of processed images

Release date: 16 October 2000
