MOC wide-angle image M12-00796

context image for 795


MOC wide-angle image M12-00796
MOC wide-angle image M12-00796
View full-size image, processed, in sinusoidal projection using 238.63°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 238.63°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M12-00796

Acquisition parameters
     Image ID (picno): M12-00796
     Image start time: 2000-02-07T02:39:42.79 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.06
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:     10 (decimal)
Derived values
Longitude of image center:    238.63°W
Latitude  of image center:     29.87°S
       Scaled pixel width:    234.83   meters
      Scaled image  width:    113.88   km
      Scaled image height:    119.05   km
     Solar longitude (Ls):    296.90°
    Local True Solar Time:     13.49   decimal hours
           Emission angle:      3.45°
          Incidence angle:     21.59°
              Phase angle:     18.27°
            North azimuth:     93.64°
              Sun azimuth:     18.81°
      Spacecraft altitude:    373.03   km
           Slant distance:    373.64   km

Policy regarding use of processed images

Release date: 16 October 2000
