MOC wide-angle image M12-00675

context image for 674


MOC wide-angle image M12-00675
MOC wide-angle image M12-00675
View full-size image, processed, in sinusoidal projection using 230.42°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 230.42°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M12-00675

Acquisition parameters
     Image ID (picno): M12-00675
     Image start time: 2000-02-06T01:19:34.68 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.02
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:     10 (decimal)
Derived values
Longitude of image center:    230.42°W
Latitude  of image center:      1.23°S
       Scaled pixel width:    242.23   meters
      Scaled image  width:    117.28   km
      Scaled image height:    118.86   km
     Solar longitude (Ls):    296.26°
    Local True Solar Time:     13.39   decimal hours
           Emission angle:      3.50°
          Incidence angle:     29.46°
              Phase angle:     27.18°
            North azimuth:     92.97°
              Sun azimuth:    315.39°
      Spacecraft altitude:    383.52   km
           Slant distance:    384.16   km

Policy regarding use of processed images

Release date: 16 October 2000
