MOC wide-angle image M12-00673

context image for 672


MOC wide-angle image M12-00673
MOC wide-angle image M12-00673
View full-size image, processed, in sinusoidal projection using 228.67°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 228.67°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M12-00673

Acquisition parameters
     Image ID (picno): M12-00673
     Image start time: 2000-02-06T01:15:16.05 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:     10 (decimal)
Derived values
Longitude of image center:    228.67°W
Latitude  of image center:     14.59°S
       Scaled pixel width:    238.13   meters
      Scaled image  width:    115.34   km
      Scaled image height:    119.13   km
     Solar longitude (Ls):    296.26°
    Local True Solar Time:     13.44   decimal hours
           Emission angle:      3.48°
          Incidence angle:     22.02°
              Phase angle:     18.88°
            North azimuth:     93.16°
              Sun azimuth:    339.04°
      Spacecraft altitude:    377.35   km
           Slant distance:    377.98   km

Policy regarding use of processed images

Release date: 16 October 2000
