MOC wide-angle image M12-00353

context image for 352


MOC wide-angle image M12-00353
MOC wide-angle image M12-00353
View full-size image, processed, in sinusoidal projection using 260.51°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 260.51°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M12-00353

Acquisition parameters
     Image ID (picno): M12-00353
     Image start time: 2000-02-04T02:09:05.57 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:     10 (decimal)
Derived values
Longitude of image center:    260.51°W
Latitude  of image center:     23.13°S
       Scaled pixel width:    235.75   meters
      Scaled image  width:    114.26   km
      Scaled image height:    119.17   km
     Solar longitude (Ls):    295.08°
    Local True Solar Time:     13.49   decimal hours
           Emission angle:      3.42°
          Incidence angle:     20.70°
              Phase angle:     17.28°
            North azimuth:     93.41°
              Sun azimuth:      0.24°
      Spacecraft altitude:    374.07   km
           Slant distance:    374.67   km

Policy regarding use of processed images

Release date: 16 October 2000
