MOC wide-angle image M12-00247

context image for 246


MOC wide-angle image M12-00247
MOC wide-angle image M12-00247
View full-size image, processed, in sinusoidal projection using 251.01°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 251.01°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M12-00247

Acquisition parameters
     Image ID (picno): M12-00247
     Image start time: 2000-02-03T00:45:59.46 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:     10 (decimal)
Derived values
Longitude of image center:    251.01°W
Latitude  of image center:      3.73°S
       Scaled pixel width:    241.04   meters
      Scaled image  width:    116.71   km
      Scaled image height:    118.97   km
     Solar longitude (Ls):    294.44°
    Local True Solar Time:     13.42   decimal hours
           Emission angle:      3.44°
          Incidence angle:     28.24°
              Phase angle:     25.81°
            North azimuth:     93.03°
              Sun azimuth:    318.65°
      Spacecraft altitude:    381.70   km
           Slant distance:    382.32   km

Policy regarding use of processed images

Release date: 16 October 2000
