MOC wide-angle image M11-02867

context image for 2866


MOC wide-angle image M11-02867
MOC wide-angle image M11-02867
View full-size image, processed, in sinusoidal projection using 236.35°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 236.35°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M11-02867

Acquisition parameters
     Image ID (picno): M11-02867
     Image start time: 2000-01-20T15:11:37.10 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:     10 (decimal)
Derived values
Longitude of image center:    236.35°W
Latitude  of image center:      6.25°S
       Scaled pixel width:    240.10   meters
      Scaled image  width:    116.26   km
      Scaled image height:    119.05   km
     Solar longitude (Ls):    286.26°
    Local True Solar Time:     13.55   decimal hours
           Emission angle:      3.50°
          Incidence angle:     28.72°
              Phase angle:     26.16°
            North azimuth:     93.05°
              Sun azimuth:    322.08°
      Spacecraft altitude:    380.21   km
           Slant distance:    380.85   km

Policy regarding use of processed images

Release date: 16 October 2000
