MOC wide-angle image M11-01827

context image for 1826


MOC wide-angle image M11-01827
MOC wide-angle image M11-01827
View full-size image, processed, in sinusoidal projection using 236.82°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 236.82°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M11-01827

Acquisition parameters
     Image ID (picno): M11-01827
     Image start time: 2000-01-13T10:37:24.18 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    236.82°W
Latitude  of image center:     10.74°S
       Scaled pixel width:    238.53   meters
      Scaled image  width:    115.51   km
      Scaled image height:    119.15   km
     Solar longitude (Ls):    281.82°
    Local True Solar Time:     13.64   decimal hours
           Emission angle:      3.48°
          Incidence angle:     27.27°
              Phase angle:     24.46°
            North azimuth:     93.10°
              Sun azimuth:    329.22°
      Spacecraft altitude:    377.84   km
           Slant distance:    378.47   km

Policy regarding use of processed images

Release date: 16 October 2000
