MOC wide-angle image M11-01716

context image for 1715


MOC wide-angle image M11-01716
MOC wide-angle image M11-01716
View full-size image, processed, in sinusoidal projection using 225.86°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 225.86°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M11-01716

Acquisition parameters
     Image ID (picno): M11-01716
     Image start time: 2000-01-12T09:10:51.06 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    225.86°W
Latitude  of image center:      1.84°S
       Scaled pixel width:    241.50   meters
      Scaled image  width:    116.93   km
      Scaled image height:    118.96   km
     Solar longitude (Ls):    281.16°
    Local True Solar Time:     13.62   decimal hours
           Emission angle:      3.43°
          Incidence angle:     32.83°
              Phase angle:     30.33°
            North azimuth:     92.96°
              Sun azimuth:    316.84°
      Spacecraft altitude:    382.42   km
           Slant distance:    383.04   km

Policy regarding use of processed images

Release date: 16 October 2000
