MOC wide-angle image M11-01588

context image for 1587


MOC wide-angle image M11-01588
MOC wide-angle image M11-01588
View full-size image, processed, in sinusoidal projection using 239.17°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 239.17°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M11-01588

Acquisition parameters
     Image ID (picno): M11-01588
     Image start time: 2000-01-11T09:31:27.45 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.06
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    239.17°W
Latitude  of image center:     25.64°S
       Scaled pixel width:    235.02   meters
      Scaled image  width:    113.92   km
      Scaled image height:    119.17   km
     Solar longitude (Ls):    280.55°
    Local True Solar Time:     13.72   decimal hours
           Emission angle:      3.41°
          Incidence angle:     23.44°
              Phase angle:     20.03°
            North azimuth:     93.46°
              Sun azimuth:      0.03°
      Spacecraft altitude:    373.07   km
           Slant distance:    373.66   km

Policy regarding use of processed images

Release date: 16 October 2000
