MOC wide-angle image M11-00033

context image for 32


MOC wide-angle image M11-00033
MOC wide-angle image M11-00033
View full-size image, processed, in sinusoidal projection using 262.28°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 262.28°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M11-00033

Acquisition parameters
     Image ID (picno): M11-00033
     Image start time: 2000-01-01T04:28:29.68 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    262.28°W
Latitude  of image center:     16.86°S
       Scaled pixel width:    236.72   meters
      Scaled image  width:    114.67   km
      Scaled image height:    119.23   km
     Solar longitude (Ls):    274.19°
    Local True Solar Time:     13.79   decimal hours
           Emission angle:      3.46°
          Incidence angle:     26.53°
              Phase angle:     23.39°
            North azimuth:     93.31°
              Sun azimuth:    340.60°
      Spacecraft altitude:    375.22   km
           Slant distance:    375.84   km

Policy regarding use of processed images

Release date: 16 October 2000
