MOC wide-angle image M10-03537

context image for 3536


MOC wide-angle image M10-03537
MOC wide-angle image M10-03537
View full-size image, processed, in sinusoidal projection using 264.67°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 264.67°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M10-03537

Acquisition parameters
     Image ID (picno): M10-03537
     Image start time: 1999-12-30T03:22:50.20 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.06
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    264.67°W
Latitude  of image center:     30.78°S
       Scaled pixel width:    234.20   meters
      Scaled image  width:    113.58   km
      Scaled image height:    119.08   km
     Solar longitude (Ls):    272.90°
    Local True Solar Time:     13.88   decimal hours
           Emission angle:      3.45°
          Incidence angle:     25.56°
              Phase angle:     22.13°
            North azimuth:     93.74°
              Sun azimuth:      9.39°
      Spacecraft altitude:    372.10   km
           Slant distance:    372.70   km

Policy regarding use of processed images

Release date: 16 October 2000
