MOC wide-angle image M10-03379

context image for 3378


MOC wide-angle image M10-03379
MOC wide-angle image M10-03379
View full-size image, processed, in sinusoidal projection using 255.76°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 255.76°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M10-03379

Acquisition parameters
     Image ID (picno): M10-03379
     Image start time: 1999-12-29T02:00:50.59 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    255.76°W
Latitude  of image center:      7.73°S
       Scaled pixel width:    239.34   meters
      Scaled image  width:    115.90   km
      Scaled image height:    119.11   km
     Solar longitude (Ls):    272.24°
    Local True Solar Time:     13.79   decimal hours
           Emission angle:      3.49°
          Incidence angle:     31.17°
              Phase angle:     28.47°
            North azimuth:     93.10°
              Sun azimuth:    325.89°
      Spacecraft altitude:    379.04   km
           Slant distance:    379.68   km

Policy regarding use of processed images

Release date: 16 October 2000
