MOC wide-angle image M10-03227

context image for 3226


MOC wide-angle image M10-03227
MOC wide-angle image M10-03227
View full-size image, processed, in sinusoidal projection using 241.22°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 241.22°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M10-03227

Acquisition parameters
     Image ID (picno): M10-03227
     Image start time: 1999-12-28T00:25:42.48 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.06
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    241.22°W
Latitude  of image center:     25.48°S
       Scaled pixel width:    235.35   meters
      Scaled image  width:    114.08   km
      Scaled image height:    119.14   km
     Solar longitude (Ls):    271.57°
    Local True Solar Time:     13.87   decimal hours
           Emission angle:      3.47°
          Incidence angle:     25.52°
              Phase angle:     22.07°
            North azimuth:     93.49°
              Sun azimuth:    358.00°
      Spacecraft altitude:    373.53   km
           Slant distance:    374.15   km

Policy regarding use of processed images

Release date: 16 October 2000
