MOC wide-angle image M10-03105

context image for 3104


MOC wide-angle image M10-03105
MOC wide-angle image M10-03105
View full-size image, processed, in sinusoidal projection using 231.07°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 231.07°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M10-03105

Acquisition parameters
     Image ID (picno): M10-03105
     Image start time: 1999-12-26T23:00:53.24 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    231.07°W
Latitude  of image center:     11.18°S
       Scaled pixel width:    238.66   meters
      Scaled image  width:    115.58   km
      Scaled image height:    119.13   km
     Solar longitude (Ls):    270.91°
    Local True Solar Time:     13.83   decimal hours
           Emission angle:      3.49°
          Incidence angle:     29.65°
              Phase angle:     26.74°
            North azimuth:     93.09°
              Sun azimuth:    331.10°
      Spacecraft altitude:    378.06   km
           Slant distance:    378.69   km

Policy regarding use of processed images

Release date: 16 October 2000
