MOC wide-angle image M10-02971

context image for 2970


MOC wide-angle image M10-02971
MOC wide-angle image M10-02971
View full-size image, processed, in sinusoidal projection using 248.43°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 248.43°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M10-02971

Acquisition parameters
     Image ID (picno): M10-02971
     Image start time: 1999-12-25T23:31:15.37 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    248.43°W
Latitude  of image center:      4.50°S
       Scaled pixel width:    240.44   meters
      Scaled image  width:    116.42   km
      Scaled image height:    119.04   km
     Solar longitude (Ls):    270.29°
    Local True Solar Time:     13.82   decimal hours
           Emission angle:      3.43°
          Incidence angle:     33.49°
              Phase angle:     30.83°
            North azimuth:     93.03°
              Sun azimuth:    322.12°
      Spacecraft altitude:    380.77   km
           Slant distance:    381.38   km

Policy regarding use of processed images

Release date: 16 October 2000
