MOC wide-angle image M10-02579

context image for 2578


MOC wide-angle image M10-02579
MOC wide-angle image M10-02579
View full-size image, processed, in sinusoidal projection using 228.11°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 228.11°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M10-02579

Acquisition parameters
     Image ID (picno): M10-02579
     Image start time: 1999-12-21T19:30:04.79 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    228.11°W
Latitude  of image center:      7.98°S
       Scaled pixel width:    239.85   meters
      Scaled image  width:    116.14   km
      Scaled image height:    119.03   km
     Solar longitude (Ls):    267.67°
    Local True Solar Time:     13.88   decimal hours
           Emission angle:      3.43°
          Incidence angle:     32.01°
              Phase angle:     29.33°
            North azimuth:     93.03°
              Sun azimuth:    327.15°
      Spacecraft altitude:    379.90   km
           Slant distance:    380.51   km

Policy regarding use of processed images

Release date: 16 October 2000
