MOC wide-angle image M10-02445

context image for 2444


MOC wide-angle image M10-02445
MOC wide-angle image M10-02445
View full-size image, processed, in sinusoidal projection using 242.97°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 242.97°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M10-02445

Acquisition parameters
     Image ID (picno): M10-02445
     Image start time: 1999-12-20T19:54:22.93 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    242.97°W
Latitude  of image center:     20.14°S
       Scaled pixel width:    236.66   meters
      Scaled image  width:    114.67   km
      Scaled image height:    119.15   km
     Solar longitude (Ls):    267.05°
    Local True Solar Time:     13.93   decimal hours
           Emission angle:      3.43°
          Incidence angle:     27.34°
              Phase angle:     24.09°
            North azimuth:     93.30°
              Sun azimuth:    347.24°
      Spacecraft altitude:    375.32   km
           Slant distance:    375.93   km

Policy regarding use of processed images

Release date: 16 October 2000
