MOC narrow-angle image M10-02361

Traverse from Candor Mensa to wall between Ophir and W Candor


MOC narrow-angle image M10-02361
MOC narrow-angle image M10-02361
View full-size image, processed, in sinusoidal projection using 73.52°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 73.52°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC narrow-angle image M10-02361

Acquisition parameters
     Image ID (picno): M10-02361
     Image start time: 1999-12-20T08:13:22.43 SCET
         Image  width:    512      pixels
         Image height:   8960      pixels
Line integration time:      0.4821 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      4
    Downtrack summing:      4
     Compression type: MOC-PRED-X-5
            Gain mode:     AA (hexadecimal)
          Offset mode:     24 (decimal)
Derived values
Longitude of image center:     73.52°W
Latitude  of image center:      5.54°S
       Scaled pixel width:      5.71   meters
      Scaled image  width:      2.92   km
      Scaled image height:     53.37   km
     Solar longitude (Ls):    266.74°
    Local True Solar Time:     13.86   decimal hours
           Emission angle:      0.22°
          Incidence angle:     33.30°
              Phase angle:     33.45°
            North azimuth:     93.02°
              Sun azimuth:    323.98°
      Spacecraft altitude:    379.93   km
           Slant distance:    379.93   km

Policy regarding use of processed images

Release date: 16 October 2000
