MOC wide-angle image M10-02145

context image for 2144


MOC wide-angle image M10-02145
MOC wide-angle image M10-02145
View full-size image, processed, in sinusoidal projection using 264.21°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 264.21°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M10-02145

Acquisition parameters
     Image ID (picno): M10-02145
     Image start time: 1999-12-17T19:22:17.96 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    264.21°W
Latitude  of image center:     17.27°S
       Scaled pixel width:    237.14   meters
      Scaled image  width:    114.88   km
      Scaled image height:    119.16   km
     Solar longitude (Ls):    265.14°
    Local True Solar Time:     13.96   decimal hours
           Emission angle:      3.44°
          Incidence angle:     28.58°
              Phase angle:     25.42°
            North azimuth:     93.26°
              Sun azimuth:    342.29°
      Spacecraft altitude:    375.93   km
           Slant distance:    376.54   km

Policy regarding use of processed images

Release date: 16 October 2000
