MOC wide-angle image M10-01636

context image for 1635


MOC wide-angle image M10-01636
MOC wide-angle image M10-01636
View full-size image, processed, in sinusoidal projection using 245.56°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 245.56°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M10-01636

Acquisition parameters
     Image ID (picno): M10-01636
     Image start time: 1999-12-13T15:25:11.38 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.04
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    245.56°W
Latitude  of image center:      7.97°S
       Scaled pixel width:    239.87   meters
      Scaled image  width:    116.15   km
      Scaled image height:    119.05   km
     Solar longitude (Ls):    262.51°
    Local True Solar Time:     13.97   decimal hours
           Emission angle:      3.49°
          Incidence angle:     33.07°
              Phase angle:     30.27°
            North azimuth:     93.06°
              Sun azimuth:    328.60°
      Spacecraft altitude:    379.89   km
           Slant distance:    380.52   km

Policy regarding use of processed images

Release date: 16 October 2000
