MOC wide-angle image M10-01271

Wind streaks on Hesperia Planum


MOC wide-angle image M10-01271
MOC wide-angle image M10-01271
View full-size image, processed, in sinusoidal projection using 248.11°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 248.11°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M10-01271

Acquisition parameters
     Image ID (picno): M10-01271
     Image start time: 1999-12-11T14:17:03.03 SCET
         Image  width:   1024      pixels
         Image height:   1440      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    248.11°W
Latitude  of image center:     27.46°S
       Scaled pixel width:    236.09   meters
      Scaled image  width:    254.81   km
      Scaled image height:    357.55   km
     Solar longitude (Ls):    261.21°
    Local True Solar Time:     14.00   decimal hours
           Emission angle:      4.25°
          Incidence angle:     27.34°
              Phase angle:     31.58°
            North azimuth:     93.15°
              Sun azimuth:      1.59°
      Spacecraft altitude:    373.68   km
           Slant distance:    374.61   km

Policy regarding use of processed images

Release date: 16 October 2000
