MOC wide-angle image M09-05903

context image for 5902


MOC wide-angle image M09-05903
MOC wide-angle image M09-05903
View full-size image, processed, in sinusoidal projection using 228.61°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 228.61°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M09-05903

Acquisition parameters
     Image ID (picno): M09-05903
     Image start time: 1999-11-25T02:21:20.70 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.02
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    228.61°W
Latitude  of image center:      0.12°S
       Scaled pixel width:    242.85   meters
      Scaled image  width:    117.58   km
      Scaled image height:    118.78   km
     Solar longitude (Ls):    250.75°
    Local True Solar Time:     14.15   decimal hours
           Emission angle:      3.47°
          Incidence angle:     39.35°
              Phase angle:     36.68°
            North azimuth:     92.92°
              Sun azimuth:    323.77°
      Spacecraft altitude:    384.52   km
           Slant distance:    385.16   km

Policy regarding use of processed images

Release date: 16 October 2000
