MOC wide-angle image M09-05201

context image for 5200


MOC wide-angle image M09-05201
MOC wide-angle image M09-05201
View full-size image, processed, in sinusoidal projection using 262.15°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 262.15°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M09-05201

Acquisition parameters
     Image ID (picno): M09-05201
     Image start time: 1999-11-21T02:07:29.74 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.06
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    262.15°W
Latitude  of image center:     28.16°S
       Scaled pixel width:    235.11   meters
      Scaled image  width:    113.99   km
      Scaled image height:    119.09   km
     Solar longitude (Ls):    248.21°
    Local True Solar Time:     14.30   decimal hours
           Emission angle:      3.46°
          Incidence angle:     31.57°
              Phase angle:     28.10°
            North azimuth:     93.60°
              Sun azimuth:      4.45°
      Spacecraft altitude:    373.34   km
           Slant distance:    373.96   km

Policy regarding use of processed images

Release date: 16 October 2000
