MOC wide-angle image M09-04299

context image for 4298


MOC wide-angle image M09-04299
MOC wide-angle image M09-04299
View full-size image, processed, in sinusoidal projection using 245.26°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 245.26°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M09-04299

Acquisition parameters
     Image ID (picno): M09-04299
     Image start time: 1999-11-16T22:14:26.16 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    245.26°W
Latitude  of image center:      6.30°S
       Scaled pixel width:    240.39   meters
      Scaled image  width:    116.40   km
      Scaled image height:    119.04   km
     Solar longitude (Ls):    245.56°
    Local True Solar Time:     14.26   decimal hours
           Emission angle:      3.49°
          Incidence angle:     36.73°
              Phase angle:     33.77°
            North azimuth:     93.05°
              Sun azimuth:    332.79°
      Spacecraft altitude:    380.68   km
           Slant distance:    381.31   km

Policy regarding use of processed images

Release date: 16 October 2000
