MOC wide-angle image M09-03981

context image for 3980


MOC wide-angle image M09-03981
MOC wide-angle image M09-03981
View full-size image, processed, in sinusoidal projection using 234.08°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 234.08°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M09-03981

Acquisition parameters
     Image ID (picno): M09-03981
     Image start time: 1999-11-15T20:47:20.55 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.02
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    234.08°W
Latitude  of image center:      0.94°N
       Scaled pixel width:    242.88   meters
      Scaled image  width:    117.60   km
      Scaled image height:    118.79   km
     Solar longitude (Ls):    244.89°
    Local True Solar Time:     14.25   decimal hours
           Emission angle:      3.48°
          Incidence angle:     40.56°
              Phase angle:     37.83°
            North azimuth:     92.96°
              Sun azimuth:    325.22°
      Spacecraft altitude:    384.56   km
           Slant distance:    385.20   km

Policy regarding use of processed images

Release date: 16 October 2000
