MOC wide-angle image M09-03688

context image for 3687


MOC wide-angle image M09-03688
MOC wide-angle image M09-03688
View full-size image, processed, in sinusoidal projection using 247.02°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 247.02°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M09-03688

Acquisition parameters
     Image ID (picno): M09-03688
     Image start time: 1999-11-14T21:07:00.93 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    247.02°W
Latitude  of image center:     25.53°S
       Scaled pixel width:    235.54   meters
      Scaled image  width:    114.17   km
      Scaled image height:    119.10   km
     Solar longitude (Ls):    244.27°
    Local True Solar Time:     14.35   decimal hours
           Emission angle:      3.47°
          Incidence angle:     32.46°
              Phase angle:     29.00°
            North azimuth:     93.49°
              Sun azimuth:      1.14°
      Spacecraft altitude:    373.84   km
           Slant distance:    374.46   km

Policy regarding use of processed images

Release date: 16 October 2000
