MOC wide-angle image M09-03398

context image for 3397


MOC wide-angle image M09-03398
MOC wide-angle image M09-03398
View full-size image, processed, in sinusoidal projection using 264.91°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 264.91°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M09-03398

Acquisition parameters
     Image ID (picno): M09-03398
     Image start time: 1999-11-13T21:38:30.07 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    264.91°W
Latitude  of image center:     15.43°S
       Scaled pixel width:    237.57   meters
      Scaled image  width:    115.07   km
      Scaled image height:    119.19   km
     Solar longitude (Ls):    243.65°
    Local True Solar Time:     14.32   decimal hours
           Emission angle:      3.47°
          Incidence angle:     33.80°
              Phase angle:     30.51°
            North azimuth:     93.24°
              Sun azimuth:    345.84°
      Spacecraft altitude:    376.50   km
           Slant distance:    377.12   km

Policy regarding use of processed images

Release date: 16 October 2000
