MOC wide-angle image M09-03396

context image for 3395


MOC wide-angle image M09-03396
MOC wide-angle image M09-03396
View full-size image, processed, in sinusoidal projection using 262.74°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 262.74°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M09-03396

Acquisition parameters
     Image ID (picno): M09-03396
     Image start time: 1999-11-13T21:33:35.07 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.06
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    262.74°W
Latitude  of image center:     30.67°S
       Scaled pixel width:    234.54   meters
      Scaled image  width:    113.74   km
      Scaled image height:    119.05   km
     Solar longitude (Ls):    243.64°
    Local True Solar Time:     14.39   decimal hours
           Emission angle:      3.46°
          Incidence angle:     33.11°
              Phase angle:     29.66°
            North azimuth:     93.73°
              Sun azimuth:      9.34°
      Spacecraft altitude:    372.62   km
           Slant distance:    373.23   km

Policy regarding use of processed images

Release date: 16 October 2000
