MOC wide-angle image M09-03359

context image for 3358


MOC wide-angle image M09-03359
MOC wide-angle image M09-03359
View full-size image, processed, in sinusoidal projection using 237.64°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 237.64°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image M09-03359

Acquisition parameters
     Image ID (picno): M09-03359
     Image start time: 1999-11-13T19:44:07.32 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.03
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    237.64°W
Latitude  of image center:      5.32°S
       Scaled pixel width:    240.70   meters
      Scaled image  width:    116.55   km
      Scaled image height:    119.00   km
     Solar longitude (Ls):    243.60°
    Local True Solar Time:     14.29   decimal hours
           Emission angle:      3.48°
          Incidence angle:     37.44°
              Phase angle:     34.48°
            North azimuth:     93.02°
              Sun azimuth:    332.47°
      Spacecraft altitude:    381.16   km
           Slant distance:    381.79   km

Policy regarding use of processed images

Release date: 16 October 2000
